Thread
Size

Thread
Call Out

Grip
Range

Grip
Call Out

Hole Size
+.006
-.000

HD
土.010
土.205*

HH
±.003

L
±.015

D
MAX.

IL
MAX.

LB
±.015

ILB
MAX.

IATD*
MAX.

6-32 UNC

632

.020-.080

80

17/64(.2656)

.390

.030

.420

.265

.305

.740

.640

.610

6-32UNC

632

.080-.130

130

17/64(.2656)

.390

.030

.470

.265

.305

.740

.580

.670

8-32UNC

832

.020-.080

80

17/64(.2656)

.390

.030

.420

.265

.305

.740

.640

.610

8-32UNC

832

.080-.130

130

17/64(2656)

390

030

470

265

305

740

580

670

10-24UNC

1024

.020-.130

130

19/64(.2969)

.415

.030

.475

.296

.315

.990

.845

.730

10-24UNC

1024

. 130-.225

225

19/64(.2969)

.415

.030

.585

.296

.315

.990

.735

.840

10-32 UNF

1032

.020-.130

130

19/64(.2969)

.415

.030

.475

.296

.315

.990

.845

.730

10-32 UNF

1032

. 130-.225

225

19/64(.2969)

.415

.030

.585

.296

.315

.990

.735

.840

1/4-20 UNC

420

.027-.165

165

25/64(.3906)

.500

.030

.580

.390

.380

1.190

1.005

.895

1/4-20 UNC

420

.165-.260

260

25/64(.3906)

.500

.030

.680

.390

.380

1.190

.905

1.035

5/16-18 UNC

518

.027-.150

150

17/32(.5312)

.685*

.035

.690

.530

.470

1.390

1.175

.995

5/16-18 UNC

518

. 150-.312

312

17/32(.5312)

.685*

.035

.805

.530

.425

1.390

1.025

1.120

3/8-16 UNC

616

.027-.150

150

17/32(.5312)

.685*

.035

.690

.530

.470

1.390

1.175

.995

3/8-16 UNC

616

150-.312

312

17/32(.5312)

.685*

.035

.805

.530

.425

1.390

1.025

1.120

1/2-13 UNC

813

063-.200

200

11/16(.6875)

.865*

.047

1.150

.685

.850

2.365

2.070

1.505

1/2-13 UNC

813

200-.350

350

11/16(.6875)

.865*

.047

1.300

.685

.850

2.365

1.920

1.505

1/2-13 UNC

813

.365-.500

500

11/16(.6875)

.865*

.047

1.450

.685

.860

2.365

1.770

1.505

Thread
Size

Thread
Call Out

Grip
Range

Grip
Call Out

Hole Size
+0,15
-.000

HD
±0,25
±.0,64*

HH
±0,08

L
±0,38

D
MAX.

IL
MAX.

LB
±.0,38

I LB
MAX.

IATD*
MAX

M4x0,7 ISO

470

0,50-2,00

2.0

6,75

9,91

0,76

10,67

7,75

18,80

16,26

15,49

M4x0,7 ISO

470

2,00-3,30

3.3

6,75

9,91

0,76

11,94

7,75

18,80

14,73

17,02

M5x0,8 ISO

580

0,50-3,30

3.3

7,60

10,54

0,76

12,07

8,00

25,15

21,46

18,54

M5x0,8 ISO

580

3,30-5,70

5.7

7,60

10,54

0,76

14,86

8,00

25,15

18,67

21,34

M6x1,0 ISO

610

0,70-4,20

4.2

10,00

12,70

0,76

14,73

9,65

30,23

25,53

22,73

M6x1,0 ISO

610

4,20-6,60

6.6

10,00

12,70

0,76

17,27

9,65

30,23

22,99

26,29

M8x1,25 ISO

8125

0,70-3,80

3.8

13,50

17,40*

0,89

17,53

11,94

35,31

29,85

25,27

M8x1,25 ISO

8125

3,80-7,90

7.9

13,50

17,40*

0,89

20,45

10,80

35,31

26,04

28,45

M 10x1,5 ISO

1015

0,70-3,80

3.8

13,50

17,40*

0,89

17,53

11,94

35,31

29,85

25,27

M 10x1,5 ISO

1015

3,80-7,90

7.9

13,50

17,40*

0,89

20,45

10,80

35,31

26,04

28,45

M12x1,75 ISO

12175

1,60-5,10

5.1

17,45

21,97*

1,19

29,21

21,59

60,07

52,58

38,23

M12x1,75 ISO

12175

5,10-8,90

8.9

17,45

21,97*

1,19

33,02

21,59

60,07

48,77

38,23

M12x1,75 ISO

12175

8,90-12,7

12.7

17,45

21,97*

1,19

36,83

21,84

60,07

44,96

38,23
